Tiffany Sliding Door

PRL's most innovative and popular system, the Tiffany, is designed to be used with single, double or bypass doors using a heavy duty petite track to accommodate limited, narrow entrances.

Product Details

Hung a minimal ceiling or wall mount track, the Tiffany uses a wall or head fascia mount application. This interior all-glass top hung sliding door system features circular patch fitting hardware and is available with either round or square rollers.

PRL offers several distinguished options for the Tiffany. Fabricated to accommodate 3/8” and ½” tempered glass thicknesses, we offer premium quality brushed and polished stainless steel hardware finishes. Select from our impressive array of lock and handle options such as patch and center locks, locking ladder pulls, offset and standard C pulls. We also provide a number of beautiful colored and textured glass options. To make your interior all-glass sliding doors stand out above the rest, adorn them with bronze, starphire, grey or textured glass panels to dazzle and impress.

2 Rollers - 200 lbs / 3 Rollers - 275 lbs
Ceiling Mount & Fascia Mount
Patch lock, Center lock or Locking ladder pull
Standard C Pull, Ladder Pull, Finger Pull, Offset Pull or Locking Ladder Pull

GLASS TYPES

HARDWARE FINISHES

CONFIGURATIONS

Styles

SHPDT

Track with channel / Ceiling Mount with sidelite

SHPST

Single track only / Ceiling Mount

PLTTTFT

Used for fascia mount only / Facial Mount

Product Overview

FRAMELESS ALL GLASS TIFFANY SLIDER

PRL can supply the Tiffany tracks in nearly any finish required. They are typically clad in stainless steel to match the rollers however they can be Anodized or Powder coated as well to suit your design needs. There are 2 standard track profiles. We carry the 1-3/8 x 1-5/8 single track (SHPST) for applications with doors only, whether it be a single or pair. We also carry 2-3/8" x 1-5/8" track (SHPDT) wich has regle for wet glazing sidelites into your system. Each application is looked at custom and we can run tracks full width of elevation for an even head sightline or we can offer the single track at door opening and sliding area only, with end caps of course, for less metal look. If the client is wanting to surface mount the track directly to the face of the wall a special track (PLTTTFT) will need to be used.

TRACKS OPTIONS

PRL can supply the Tiffany tracks in nearly any finish required. They are typically clad in stainless steel to match the rollers however they can be Anodized or Powder coated as well to suit your design needs. There are 2 standard track profiles. We carry the 1-3/8 x 1-5/8 single track(SHPST) for applications with doors only, whether it be a single or pair. We also carry a 2-3/8” x 1-5/8 track(SHPDT) which has a reglet for wet glazing sidelites into your system. Each application is looked at custom and we can run tracks full width of elevation for an even head sightline or we can offer the single track at door opening and sliding area only, with end caps of course, for less metal look. If the client is wanting to surface mount the track directly to the face of the wall a special track(PLTTTFT) will need to be used. Please note for this application, it is the glaziers responsibility to ensure adequate support in the wall to withstand the weights.
